Paulin® 108-018 Pozi-Lok® 108 Nylon Insert Standard Stop Lock Nut, Carbon Steel, Zinc Plated


Description

Paulin® Lock Nut, Nylon Insert Standard Stop, Series: Pozi-Lok® 108, Measurement System: Imperial, Carbon Steel, Zinc Plated, 0.453 in Height, 9/16 in Width Across Flats, UNC Thread

These prevailing torque locknuts offer excellent vibration resistance and a wide range of adjustment. The nylon collar prevents liquid seepage and internal corrosion. It is smaller than the bolt diameter and as the bolt enters the collar, the thread form is impressed in the nylon. The resulting compressive forces exert constant friction grip on the bolt and prevent loosening. These nuts may be re-used up to 50 times because the "elastic memory" feature of the nylon causes it to return to its original shape. May be used with grade 2 and grade 5 screws up to 250 deg F. Bright zinc chromate plated.

Specifications

Finish Zinc Plated
Height 0.453 in
Material Carbon Steel
Measurement System Imperial
Series Pozi-Lok® 108
Thread Type UNC
Type Nylon Insert Standard Stop
Width Across Flats 9/16 in
